Products产品中心

One drawing is all we need一张图纸,即可开模

All parts below are fully custom — shape, size, thickness, hardness, color, adhesive and packaging are made to your specification. Send us a PDF, DWG or AI file, or mail us a sample to reverse-engineer.以下产品均为全定制——外形、尺寸、厚度、硬度、颜色、背胶与包装均按您的规格生产。支持PDF/DWG/AI图纸,也可寄样测绘。

Custom die-cut gaskets

Custom Die-Cut Gaskets定制模切垫片

Flange gaskets, pump & compressor seals, equipment gaskets. Solid silicone, EPDM, NBR, CR, FKM; 0.15–20 mm thickness; holes, corners and complex outlines no problem.法兰垫、泵阀压缩机密封垫、设备垫片。固态硅胶/EPDM/丁腈/氯丁/氟橡胶,厚度0.15–20mm,任意孔位与复杂外形。

Silicone sealing washers

Silicone Washers & Rings硅胶垫圈/密封圈

Flat and stepped sealing washers, O-ring style flats, pipe seals. Food-grade (FDA / LFGB) and medical-grade platinum silicone stock available.平垫、台阶垫、法兰密封圈、管路密封件。可选食品级(FDA/LFGB)与医用级铂金硫化硅胶。

Thermal interface pads

Thermal Interface Pads导热垫片

Gap filler pads 1–6 W/m·K cut with sharp inner corners for CPUs, power modules, LED drivers and EV battery packs. Fiberglass-reinforced options.1–6 W/m·K导热垫,精确内角模切,适用于CPU、电源模块、LED驱动及动力电池,可选玻纤增强。

Anti-vibration pads

Anti-Vibration & Cushioning Pads减震缓冲垫

Mounting pads, machine feet, shock-absorbing pads in solid rubber or closed-cell sponge for HVAC, compressors and industrial equipment.设备脚垫、安装减震垫、缓冲垫,实心胶或闭孔泡棉,适用于暖通、压缩机与工业设备。

Adhesive-backed die-cut parts

Adhesive-Backed Parts背胶模切件

Gaskets and pads laminated with 3M / Nitto / tesa adhesives, kiss-cut on release liner for fast peel-and-stick assembly lines.复合3M/日东/德莎胶带,克辛模切(半断)带离型纸,适合流水线快速撕膜装配。

Foam seals and dust filters

Foam Seals & Dust Filters泡棉密封件/防尘网

EVA, PU and EPDM foam seals, speaker dust meshes, vent and breath filters for enclosures, speakers and display assemblies.EVA/PU/EPDM泡棉密封条、喇叭防尘网、透气阀与防水透气膜,适用于外壳、音箱与显示模组。

Insulation sheets

Insulation & Barrier Sheets绝缘片/防火 barrier

PET, PC and fire-retardant insulation sheets cut between battery cells, PCBs and housings; UL 94 V-0 grades available.PET/PC及阻燃绝缘片,用于电芯间隔、PCB与外壳之间,可选UL 94 V-0阻燃等级。

Food grade silicone parts

Food & Medical Grade Parts食品级/医用级制品

Sealing rings, jar gaskets, brewing and dairy seals, medical device gaskets from certified platinum-cured silicone.密封圈、罐盖垫、酿造乳制品密封件、医疗设备垫片,均采用认证铂金硫化硅胶。

Need something not listed?没找到想要的?

If it can be cut from sheet or roll material, we can make it. Tell us the application and we will propose the material.凡是片材卷材能裁切的产品我们都可加工。告诉我们使用场景,由我们推荐材料方案。

Ask Our Engineers咨询工程师
Material selection guide材料选型指南

Pick the right material for your application为您的应用选择合适的材料

Typical values for commonly stocked grades. All materials are purchased with mill certificates — we are happy to send data sheets on request.以下为常备牌号的典型参数。所有材料均带原厂证书,可按需提供数据表。

Material材料 Temp. Range耐温范围 Hardness硬度 Key Properties特性
Silicone (VMQ)-60 ~ +230 °C30–80 Shore A Wide temperature range, weathering & UV stable, food/medical grades耐温范围宽,耐候抗UV,有食品/医用级
EPDM-50 ~ +150 °C40–80 Shore A Excellent water, steam & ozone resistance; HVAC and outdoor sealing耐水、耐蒸汽、耐臭氧,适用于暖通与户外密封
NBR-40 ~ +120 °C50–80 Shore A Best oil & fuel resistance; pumps, hydraulics, fuel systems耐油耐燃油性能佳,用于泵、液压与燃油系统
CR (Neoprene)-40 ~ +100 °C40–75 Shore A Balanced weather, oil & flame resistance; general purpose耐候/耐油/阻燃均衡,通用型选择
FKM (Viton-type)-20 ~ +250 °C60–90 Shore A High temperature plus aggressive chemicals, oils and solvents耐高温及强腐蚀化学品、油品与溶剂
Sponge / Foam-40 ~ +120 °CSoft–Medium Compressible sealing, dust & water ingress (IP) protection可压缩密封,防尘防水(IP等级)防护
Thermal Pad-40 ~ +150 °CShore 00 30–70 1–6 W/m·K thermal conductivity, electrically insulating gap filler导热系数1–6 W/m·K,电气绝缘间隙填充
PET / PC Film-30 ~ +120 °C— Electrical insulation, fire-retardant (UL 94) barrier layers电气绝缘,可提供UL 94阻燃等级

Send your drawing — quote in 24 h发送图纸,24小时内报价

Include target quantity, thickness and material (or application) for the fastest response.附上数量、厚度与材料要求(或使用场景),我们回复更快。

Request a Quote立即询价
